Description
Model Information
-
- System
- LHD687-FC
- Speaker System
- S60T1
Size(W x H x D, mm)
-
- Main
- 360 X 58 X 298.5
- Front Speaker
- 233 X 998 X 300
-
- Freight (20ft/40ft/40ft HC)
- 96/198/262
CH
-
- CH
- 4.2
POWER OUTPUT THD 10%
-
- Total
- 1250W (Only bypass Condition_measure)
- Front L/R
- 200/200
-
- Surround L/R
- 200/200
- Sub-Woofer
- 200/200
DESIGN(MAINSET)
-
- Front & Rear cabinet (tray)
- Yes
3D COMPATIBILITY
-
- 3D / 2D
- 2D
In & Out(Front)
-
- Display
- FLD
- USB
- 1
-
- Mic
- 2
- Audio In
- Yes
In & Out(Rear)
-
- Video Out (Composite)
- Yes
- Audio Input (Audio L/R)
- Yes
-
- Audio Input (Optical)
- 1
- HDMI (Out)
- 1
-
- FM
- Yes
- Speaker Terminal (Composing of channel)
- Front (2) Srround (2) Woofer (2)
-
- Speaker Terminal (Terminal Type)
- Front (Spring) Srround (Spring) Woofer (LAN)
CONVENIENCE
-
- SIMPLINK
- Yes
- Speaker Level Trim
- Yes
-
- Speaker Distance (channel delay)
- Yes
- Test Tone
- Yes
-
- Mute
- Yes
- A/V Sync Delay(Audio Delay)
- Yes
-
- Dimmer
- Yes
- Sleep
- Yes
-
- Volume on TV
- Yes
- USB Direct Recording
- Yes (EU, CIS suffix don’t support it)
-
- TV Sound (direct key) / TV Sound connect (Auto PWR on/off by optical)
- Yes
- TV Sound Sync (Optical / Bluetooth)
- Yes
-
- Dynamic Range Control
- Yes
- Bluetooth (Rx /Tx)
- Yes
KARAOKE
-
- Mic Volume / Echo Volume
- Yes
- Fanfare
- Yes
-
- Scoring
- Yes
- CD Voice Remover
- Yes
FCC
-
- Closed Caption
- Yes
PLAYABLE DISC TYPE
-
- DVD(NTSC)
- Yes
- DVD(PAL)
- Yes
-
- DVD-R
- Yes
- DVD-RW(Video/VR Mode)
- Yes
-
- DVD+R
- Yes
- DVD+RW(Video mode)
- Yes
-
- Video CD/Super VCD
- Yes/Yes
- Audio CD
- Yes
-
- CD-R/CD-RW
- Yes
VIDEO FORMAT
-
- MPEG2
- Yes
- Xvid
- Yes
AUDIO FORMAT(DECODING)
-
- LPCM
- LPCM
- Dolby Digital
- Yes (Dolby Audio)
-
- MPEG 1/2 L2
- Yes
- MP3/ID3 Tag
- Yes/Yes
-
- WMA
- Yes
GRAPHICS/SUBTITLE FORMAT
-
- Format
- 2bit/8bit Sub-picture (Text-based Subtitle)
VIDEO FEATURES
-
- GUI/MENU Language
- Option
- Video DAC
- 148MHZ/12bit
-
- NTSC/PAL Hz
- 60Hz/50Hz
- Resolution
- upto 1080p24/60Hz
VBI
-
- WSS/CGMS-A/Closed Caption/Macrovsion
- Yes
- NTSC⇔PAL Conversion
- Yes
-
- Last Scene memory
- Yes
- Screen Saver
- Yes
-
- Auto Power Off
- Yes
- Parental Lock
- Yes
-
- Initial logo
- Yes
- 1080p Upscaling
- Yes
Trick Play
-
- Fast Forward
- Yes
- Fast Back
- Yes
-
- Forword Slow
- Yes
- Reverse Slow
- Yes
-
- Pause
- Yes
- Forward Step
- Yes
Search
-
- Title/Track
- Yes
- Chapter
- Yes
-
- Time
- Yes
Repeat Play
-
- Title/Track
- Yes
- Chapter
- Yes
Resume Stop
-
- Resume Stop
- Yes
- Random
- Yes
POWER
-
- SMPS
- Option
- Power Off Consumption
- 0.5W ↓
RADIO
-
- Tuner Type
- PLL
- Tuning Up/Down
- Yes
-
- Preset Up/Down
- Yes
- Band
- Yes
-
- Preset Memory
- 50 Station
Speaker Front
-
- Model Name
- S60T1-S
- SPL
- 82dB
-
- System
- Closed Type
- Woofer Unit
- 3″ Paper
-
- Impedance
- 3Ω
- Magnetic Shielding
- Non-Shielded
Speaker Rear
-
- Model Name
- built in front speaker
- SPL
- 82dB
-
- System
- Closed Type
- Woofer Unit
- 3″ Paper
-
- Impedance
- 3Ω
- Magnetic Shielding
- Non-Shielded
Speaker Subwoofer
-
- Model Name
- built in front speaker
- SPL
- 83dB
-
- System
- Bass Reflex
- Woofer Unit
- 6.5″ Paper (1EA)
-
- Impedance
- 3Ω
- Magnetic Shielding
- Non-Shield
Equalizer
-
- Standard
- Yes
- USER EQ
- Yes
-
- BASS BLAST
- Yes
- Football
- Yes
Manual
-
- Type
- Printing Book
- Full Manual / Simple Manual
- Simple Manual
-
- Warranty Card
- Yes
Accessory(Remote Control)
-
- Type
- CB1
- Battery(Size)
- AAA x 1
Accessory(Others)
-
- Batteries (Remote Controller)
- Yes
- FM / AM Antenna
- Yes
-
- RCA Code(Video), Yellow, 1P
- Yes
- HDMI Cable
- â–³ (1.5M)
-
- Carton Box Type (Tip-on, Offset, Flexo)
- Flexo
